mm

mm

mm

mm

mm

KW

mm

kg

Plate Length

Top roller dia.

No Prebend

Prebend

Bottom Roller dia.

Motor

LxWxH

Weight

Vi-HSS 2_280

2050

280

20

16

280

16,5

4350x1700x1850

8550

Vi-HSS 2_320

2050

320

25

20

320

20

4350x1800x1950

10500

Vi-HSS 2_350

2050

350

30

25

350

23,5

4350x1900x1950

11500

Vi-HSS 2_380

2050

380

40

30

380

31,5

4850x2250x2350

14650

Vi-HSS 2_400

2050

400

45

35

400

38,5

4850x2250x2350

16500

Vi-HSS 2_460

2050

460

50

40

460

38,5

4850x2300x2350

19800

Vi-HSS 2_500

2050

500

55

45

500

63

5550x2800x2900

33500

Vi-HSS 2_550

2050

550

60

50

550

70

5700x2900x2950

40000

Vi-HSS 3_280

3100

280

12

10

280

16,5

5350x1700x1850

10600

Vi-HSS 3_320

3100

320

16

12

320

20

5350x1800x1950

12750

Vi-HSS 3_350

3100

350

20

16

350

23,5

5350x1900x1950

14450

Vi-HSS 3_380

3100

380

25

20

380

31,5

5850x2250x2350

19200

Vi-HSS 3_400

3100

400

30

25

400

38,5

5850x2250x2350

20200

Vi-HSS 3_460

3100

460

40

30

460

38,5

5850x2300x2350

25100

Vi-HSS 3_500

3100

500

45

35

500

63

6600x2800x2900

38500

Vi-HSS 3_550

3100

550

50

40

550

70

6750x2900x2950

47000

Vi-HSS 3_580

3100

580

60

45

580

73

6750x2950x2950

50000

Vi-HSS 3_620

3100

620

70

60

620

123

7200x3250x3250

62000

Vi-HSS 3_680

3100

680

85

70

680

150

7700x3500x3600

82500

Vi-HSS 4_280

4100

280

8

6

280

16,5

6450x1700x1850

13000

Vi-HSS 4_320

4100

320

10

8

320

20

6450x1800x1950

14750

Vi-HSS 4_350

4100

350

13

10

350

23,5

6450x1900x1950

17150

Vi-HSS 4_380

4100

380

15

12

380

31,5

6950x2250x2350

22000

Vi-HSS 4_400

4100

400

20

16

400

38,5

6950x2250x2350

23500

Vi-HSS 4_460

4100

460

25

20

460

38,5

6950x2300x2350

29500

Vi-HSS 4_500

4100

500

35

25

500

63

7600x2800x2900

43500

Vi-HSS 4_550

4100

550

40

30

550

70

7750x2900x2950

54000

*** Given capacities are for mild steel 260Mpa

***Bending diameters are 5 times of the top roller
